MaterialTerminal Body:Copper Plating:Tin
WIRE
RANGE |
ITEM NO. |
DIMENSION mm |
Q’ TY
BOX |
mm2
(A.W.G) |
l |
a |
d |
s |
| 0.5~1.5 |
DPNT1 |
8.0 |
5.0 |
1.6 |
0.8 |
1000 |
| 1.5~2.5 |
DPNT2.5 |
8.0 |
5.0 |
2.3 |
0.8 |
1000 |
| 2.5~6 |
DPNT6 |
9.0 |
6.0 |
3.6 |
1.0 |
1000 |
| 10 |
DPNT10 |
10.0 |
8.0 |
4.5 |
1.1 |
500 |
| 16 |
DPNT16 |
11.0 |
10.0 |
5.8 |
1.2 |
500 |
| 25 |
DPNT25 |
14.0 |
11.0 |
7.5 |
1.5 |
250 |
| 35 |
DPNT35 |
16.0 |
12.0 |
9.0 |
1.6 |
200 |
| 50 |
DPNT50 |
19.0 |
16.0 |
11.0 |
1.8 |
50 |
| 70 |
DPNT70 |
19.0 |
17.0 |
13.0 |
2.0 |
50 |
| 95 |
DPNT95 |
20.0 |
18.0 |
15.0 |
2.5 |
25 |
| 120 |
DPNT120 |
22.0 |
20.0 |
16.5 |
3.0 |
25 |
| 150 |
DPNT150 |
26.0 |
24.0 |
19.0 |
3.2 |
10 |
|
|
